Parameter Manual
Operating Instructions, 08/2013, 6FC5397-8EP40-0BA0
79
Machine data
2.2 General machine data
Description: For probes with e.g. radio transmission, the probe deflection can be detected
in the NC only with delay.
With this MD, the transmission link delay between the probe deflection and
its detection is set in the control.
The measured value is corrected internally by the control by the distance
that corresponds to the traversing motion during this time before measuring
(modeling).
It is practicable to set values only up to a maximum of 15 position control-
ler cycles.
Anyhow, the modeling could not work with the expected accuracy with values
greater than that. In this case, the input value is therefore limited inter-
nally by the software to 15 position controller cycles (without any further
feedback).
Description: Simulation of the probe only works when all axes are simulated.
Value = 0: the probe is triggered on the programmed end position.
Value = 1-8: the probe is triggered via digital output with the number=value.
Value = 9: reserved
Description: The switching position of the probe is offset by the value.
The offset is only active with the simulated probes and MD 13230
$MN_MEAS_PROBE_SOURCE=0.
Description: User data is stored in the NCK-PLC interface, and can be read by the PLC user
from the DB20 during the runup.
Description: User data is stored in the NCK-PLC interface and can be read by the PLC user
from the DB20 during the PLC runup.
13220 MEAS_PROBE_DELAY_TIME N10, N09 FBA/IAD
s Delay time between probe deflection and recognition DOUBLE PowerOn
-
- 2 0.0, 0.0 0 0.1 3/3
13230 MEAS_PROBE_SOURCE N10, N09 -
- Probe simulation BYTE PowerOn
-
-- 0 0 9 3/2
13231 MEAS_PROBE_OFFSET N10, N09 -
mm/inch,
degrees
Probe offset DOUBLE Immediately
-
-- 0.1 - - 7/7
14510 USER_DATA_INT N03 P3
- User data (INT) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... -32768 32767 7/3
14512 USER_DATA_HEX N03 P3
- User data (HEX) DWORD PowerOn
-
- 32 0, 0, 0, 0, 0, 0, 0, 0... 0 0x0FF 7/3
