Tension jacks
The machine control panel is attached using 6 tension jacks (tightening torque, 0.5 Nm).






Figure 7-14 Panel cut-out for the machine control panel MCP 310C PN
Dimension drawing

5]
PP



① In the sealing area
② Mounting frame
③ Tension jack (6 parts) - tightening torque 0.5 Nm
Figure 7-15 MCP 310C PN dimensions
Connectable components
7.2 MCP 310C PN
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 117
