Parameter Value
As output:
Voltage 18 V to 30 V
Load current per output, maximum 0.5 A
Load current per connector, maximum 1 A
Signal propagation times L → H: 50 μs
H → L: 200 μs
Galvanic isolation Yes: The reference potential is terminal1M/1P24 (24 V
DC)
Digital outputs
Table 6-8 Technical data of the digital outputs at X242/X252
Parameter Value
Voltage 18 V to 30 V
Load current per output, maximum 0.5 A
Load current per connector, maximum 1 A
Signal propagation times L → H: 50 μs
H → L: 200 μs
Galvanic isolation Yes: The reference potential is terminal 3M/3P24 (24
V DC).
6.6 DRIVE-CLiQ
6.6.1 DRIVE-CLiQ interface
Pin assignment at X100 - X102
PIN Signal name Signal type Meaning
1 TXP O Transmit data +
2 TXN O Transmit data -
3 RXP I Receive data +
4 -- -- Reserved
5 -- -- Reserved
6 RXN I Receive data -
7 -- -- Reserved
8 -- -- Reserved
A -- -- Reserved
B -- -- Reserved
Interface description
6.6 DRIVE-CLiQ
PPU
84 Manual, 01/2014, 6FC5397-2DP40-3BA3
