Table 7-61 Input image for MCP 310C PN and MCP 483C PN
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB122 Axis selection switch
KT8 KT7 KT6 KT5 KT4 KT3 KT2 KT1
F2 F1
2
3
2
2
2
1
X55.2 X55.1 X52.3 X52.2 X52.1 X51.3 X51.2 X51.1
EB123 - - - - - - - KT9
F3
X55.3
Table 7-62 Input image for MCP Interface PN
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB124
Axis selection switch
KT8 KT7 KT6 KT5 KT4 KT3 KT2 KT1
F2 F1
2
3
2
2
2
1
X55.2 X55.1 X52.3 X52.2 X52.1 X51.3 X51.2 X51.1
EB125
- - - - - - - KT9
F3
X55.3
Note
Within the SINUMERIK control, the handwheel data is processed directly by the NC and is
not available to the PLC.
7.5.5 Technical data
Mini handheld unit
Parameter Value
Enabling button isolated, two-channel NO contact, 3-positions
Emergency Stop button isolated, two-channel NC contact, locked by
twisting
Selection switch 5 axes: X, Y, Z, 4th axis, 5th axis, and neutral position
Jog key: Positive traverse direction
Connectable components
7.5 Mini handheld unit
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 163
