DRIVE-CLiQ interface Connection with
X201 Remains empty
X202 Motor encoder for feedrate 2nd expansion axis (via Sensor Module)
Double Motor Module
X200 X101 of the PPU
X201 Remains empty
X202 Motor encoder for feedrate 1st expansion axis
X203 Motor encoder for feedrate 2nd expansion axis
1)
Remains empty if only one Single Motor Module is used
Table 5-4 Assigning the DRIVE-CLiQ interfaces at the DMx20 to assign a direct measuring system to the feed axes.
DRIVE-CLiQ interface Feed axis
X500 X501 of the TM54F
X102 of the PPU (if a TM54F is not being used)
X501 Direct encoder, feedrate 1 at the S120 Combi
X502 Direct encoder, feedrate 2 at the S120 Combi
X503 Direct encoder, feedrate 3 at the S120 Combi → only for 4-axis S120 Combi
Remains empty for 3-axis S120 Combi
X504 Feedrate 1st expansion axis at the Motor Module
X505 Feedrate 2nd expansion axis at the Motor Module
Table 5-5 Assigning the DRIVE-CLiQ interfaces at the TM54F
DRIVE-CLiQ interface
X500 X102 of the control (PPU)
X501 X500 of the DMx20
If a DMx20 is not being used, then this interface remains empty.
5.2 Topology rules for S120 Booksize
Introduction
The following rules apply for wiring components with DRIVE-CLiQ. A distinction is made
between DRIVE-CLiQ rules, which must always be observed, and recommended rules, which,
when observed, do not require any subsequent changes to the topology when expansions are
made.
The maximum number of DRIVE-CLiQ components and the possible wiring form depend on
the following points:
● The binding DRIVE-CLiQ wiring rules
● The number and type of activated drives and functions on the respective Control Unit
Rules for permitted topologies
5.2 Topology rules for S120 Booksize
PPU
54 Manual, 01/2014, 6FC5397-2DP40-3BA3
