7.8.4 Technical Data
Technical specifications NX10.3
Parameter Value
Input voltage
● permissible range:
24 VDC
DC 20.4 V - 28.8 V
Current (without DRIVE-CLiQ and digital outputs) 0.8 A
Digital inputs 6
Digital inputs/outputs 4 (parameterizable)
Inrush current 1.6 A
PE/ground connection On housing with M5/3 Nm screw
Heat dissipation Open-circuit ventilation
Pollution degree in acc. with EN 61800-5-1 2
Protection class in acc. with EN 61800-5-1 III (DVC A, PELV)
Degree of protection in acc. with EN 60529 IP20
Approvals cULus
Mounting position Vertical
Dimensions:
● Width
● Height
● Depth
25 mm
414 mm
272 mm
Weight, approx. 2.58 kg
Connectable components
7.8 NX10.3
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 223
