Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB115
RESET
Keyswitch
position 2
Keyswitch
position 1
Feedrate override
E (2
4
) D (2
3
) C (2
2
) B (2
1
) A (2
0
)
EB116 Direction keys
KT5
KT4
KT3
KT2
KT1
+ - Rapid
traverse
EB117 T16 KT6 6 5 4 Z Y X
EB118 Unassigned customer keys Unassigned customer keys
T9 T10 T11 T12 WCS
MCS
T13 T14 T15
EB119 Unassigned customer keys
T1 T2 T3 T4 T5 T6 T7 T8
EB120 - - - - - - - -
EB121 - - - - - - - -
EB122 KT-IN8 KT-IN7 KT-IN6 KT-IN5 KT-IN4 KT-IN3 KT-IN2 KT-IN1
EB123 - - - - - - - KT-IN9
EB124 - - - - - - - -
EB125 - - - X31
pin 6
1)
X31
pin 7
1)
X31
pin 8
1)
X31
pin 9
1)
X31
pin 10
1)
Signals marked with * are inverse signals.
1) If the 4-stage rotary spindle override switch on X31 is replaced by a 5-stage rotary switch, the input information here
can be measured in 5 stages.
Input image of the handwheel
Table 7-29 Input image for handwheel data
Byte Bit7 Bit6 Bit5 Bit4 Bit3 Bit2 Bit1 Bit0
EB m + 0 Handwheel 1 counter status
(16-bit signed, low-order byte equals byte m + 0)
EB m + 1
EB m + 2 Handwheel 2 counter status
(16-bit signed, low-order byte equals byte m + 2)
EB m + 3
Note
Within the SINUMERIK control, the handwheel data is processed directly by the NC and is
not available to the PLC.
Connectable components
7.2 MCP 310C PN
PPU
124 Manual, 01/2014, 6FC5397-2DP40-3BA3
