makes for an extremely precise incremental process. The axis selected via the control can be

positioned so that the axes are parallel. The portable handwheel offers a PPR count of 100 S/







① Handwheel

② Spiral connection cable

③ 9-pin connector

Figure 7-29 View of electronic portable handwheel

For safe storage on non-magnetic surfaces, a holder (Page 154) is available.

Output circuitry

RS 422 A: Load current ≦ 20 mA

$%

$%

Pulse diagram:

Connectable components

7.4 Electronic handwheel

PPU

Manual, 01/2014, 6FC5397-2DP40-3BA3 149
