Pin Signal name Type Pin Signal name Type
45 DO 3.6 O 46 DO 3.7 O
47 DOCOM2 VI 48 DOCOM2 VI
49 DOCOM2 VI 50 DOCOM2 VI
VI: Voltage input/VO: Voltage Output
I: Signal input/O: Signal output/GND: Reference potential (ground)
Table 7-90 Pin assignment for X333
Pin Signal name Type Pin Signal name Type
1 M GND 2 P24OUT VO
3 DI 6.0 I 4 DI 6.1 I
5 DI 6.2 I 6 DI 6.3 I
7 DI 6.4 I 8 DI 6.5 I
9 DI 6.6 I 10 DI 6.7 I
11 DI 7.0 I 12 DI 7.1 I
13 DI 7.2 I 14 DI 7.3 I
15 DI 7.4 I 16 DI 7.5 I
17 DI 7.6 I 18 DI 7.7 I
19 DI 8.0 I 20 DI 8.1 I
21 DI 8.2 I 22 DI 8.3 I
23 DI 8.4 I 24 DI 8.5 I
25 DI 8.6 I 26 DI 8.7 I
27 Not assigned - 28 Not assigned -
29 Not assigned - 30 Not assigned -
31 DO 4.0 O 32 DO 4.1 O
33 DO 4.2 O 34 DO 4.3 O
35 DO 4.4 O 36 DO 4.5 O
37 DO 4.6 O 38 DO 4.7 O
39 DO 5.0 O 40 DO 5.1 O
41 DO 5.2 O 42 DO 5.3 O
43 DO 5.4 O 44 DO 5.5 O
45 DO 5.6 O 46 DO 5.7 O
47 DOCOM3 VI 48 DOCOM3 VI
49 DOCOM3 VI 50 DOCOM3 VI
VI: Voltage input/VO: Voltage Output
I: Signal input/O: Signal output/GND: Reference potential (ground)
Cable specification:
● 50-pin ribbon cable connector: 50-pin insulation piercing connecting device with strain relief,
ribbon cables and terminal converter are required to connect the digital inputs and outputs.
● The required connecting cables (ribbon cables) must be provided by the user. Maximum
cable length: 30 m
Connectable components
7.7 PP 72/48D 2/2A PN
PPU
196 Manual, 01/2014, 6FC5397-2DP40-3BA3
