Table 7-115 Pin assignment for X124
Pin Signal name Meaning
1 + (Voltage input) Electronics power supply
2 + (Voltage input) Electronics power supply
3 M (Voltage output) Ground
4 M (Voltage output) Ground
Note
The two terminals "+" and "M" are jumpered in the connector and not in the device. This
ensures that the supply voltage is looped through.
Table 7-116 Technical data for X124
Parameter Value
Voltage 24 V DC (20.4 V - 28.8 V)
Current consumption max. 0.8 A (without load)
Max. current via the bridges in the connector 20 A at 55 °C
Note
Current consumption
The current consumption increases by the current consumption of DRIVE-CLiQ and the digital
outputs.
X122 digital inputs/outputs
Connector designation: X122
Connector type: Spring-loaded terminal 1
Max. connectable cross-section: 0.5 mm
2
Table 7-117 Pin assignment for X122
Pin Signal name Meaning
1 DI0 Digital input 0
2 DI1 Digital input 1
3 DI2 Digital input 2
4 DI3 Digital input 3
5 DI16 Digital input 16
6 DI17 Digital input 17
7 M1 Reference potential for terminals 1 to 6
8 M Ground
9 DI/DO8 Digital input/output 8 (rapid input)
Connectable components
7.8 NX10.3
PPU
220 Manual, 01/2014, 6FC5397-2DP40-3BA3
