The Ethernet cables are not included in the scope of delivery. When connecting the machine
control panel to the SINUMERIK 828D, please use the preassembled SINAMICS DRIVE-CLiQ
signal cables; from a technical point of view, these are also suitable for use with PROFINET.
NOTICE
Damage to cables
Make sure that all cables are routed so that they do not come into contact with chafing edges.
See also
Ordering data (Page 27)
Interface overview
X10 Power supply interface
X20 PLC I/O Interface port 1
X21 PLC I/O Interface port 2
X30 Interface for rotary switch feed override
X31 Interface for rotary switch spindle override/EMERGENCY STOP (optional)
X51 / X52 / X55 Interfaces for customer-specific inputs
X53 / X54 Interfaces for customer-specific outputs
X60 Interface for handwheel
X61 Reserved
S1 Switch for setting the handwheel signal type
S2 Switch for setting the MCP address
X10 power supply pin assignment
Connector designation: X10
Connector type: Terminal block, 3-pin plug connector
Pin Signal name Signal type Meaning
1 P24 V 24 V potential
2 M24 V 24 V ground
3 SHIELD V Shield connection
PLC I/O Interface pin assignment
Connector designation: X20, X21
Connector type: RJ45 socket
Connectable components
7.1 MCP 483C PN
PPU
Manual, 01/2014, 6FC5397-2DP40-3BA3 99
