Siemens SINUMERIK 840C Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
1–226
SINUMERIK 840C / SIMODRIVE 611–D (DA)
Dialog text
What must be done
or
What is wrong
Appears with the
following event
SPECIFY 2 PROGRAM
NUMBERS
When copying or renaming
part programs
––
STOP AXES The actual axis value is to
be read
Axis values must not
change.
STOP PROGRAM Editing the program being
processed
Interrupt program
(NC STOP)
TOO MANY
CHARACTERS ENTERED
Taking over an input value
(e.g. with the input key)
Input value has the wrong
format
TOOL NUMBER NOT
ALLOWED
With functions operating
with tool offsets
e.g. PRESET with a rotary
axis: In the PRESET
display “0” must be
entered for the tool offset
number
RS232C (V.24) CHANNEL
ALREADY IN RESET
On stop or stop all in
display
Data input/output
A RESET request has
already been sent. When
the softkey is pressed
again it is ignored.
RS232C (V.24) CHANNEL
NUMBER NOT CORRECT
When starting data
input/output
The RS232C (V.24)
interface number is too
large or too small
WRONG AXIS
SPECIFIED
With axis-specific functions
(e.g. Preset)
Axis does not exist
WRONG DATA NUMBER When deleting data Data item (e.g. R
parameter) with the
number entered does not
exist
WRONG G FUNCTION With technology-
dependent functions
Correct G function
WRONG MODE GROUP For functions which are
assigned to a mode group
(e.g. channel selection)
Select an alternative mode
group
WRONG PASSWORD Password input –
WRONG RS232C (V.24)
CHANNEL NUMBER
Starting data output The RS232C (V.24)
interface number is too
large or too small
WRONG VALUE
ENTERED
When inputting into display
screen forms (e.g. contour
definition)
Change value
“–” NOT ALLOWED Taking over an input value
(e.g. with the input key)
Input value has wrong
format
“=”, “CR” IN WRONG
PLACE
Taking over an input value
(e.g. with the input key)
Input value has the wrong
format
1ST NUMBER > 2ND
NUMBER
Deleting data areas The 1st number must be
smaller than the 2nd
2ND DECIMAL POINT Taking over an input value
(e.g. with the input key)
Input value has the wrong
format
END OF SECTION
1 Alarms
1.6.2 Listing of dialog texts
