Siemens SINUMERIK 840C Diagnostics Guide

04/96

Siemens AG 2001 All rights reserved 6FC5198–jAB40
1–56
SINUMERIK 840C / SIMODRIVE 611–D (DA)
3098 Error in IKA input/output data CANCEL
On changing input/output assignment of the IKA with inactive relationship (input screen or @40C), not G411.
None
A check is made to determine whether the input/output assignment of an IKA relationship contains permissible
data, and in particular whether the pairs T2/T20, T25/T25, T3/T33 contain compatible values. An error fine coding
ensues relating to block and channel number as follows:
I/O identifier:
IKA relationship
Error fine coding
0 = Input A
1 = Input B
2 = Output
KS
Error fine coding:
1; Error = “Wrong group”
2; Error = “Illegal type of axis”
3; Error = “Wrong axis number”
4; Error = “Axis/channel not available”
5; Error = “Not a real axis”
6; Error = “Wrong R parameter number”
Enter the correct values
3100 Transfer buffer already assigned Acknowledgement key
S During computer link operation
S No data transfer between NC and host computer
This alarm is not displayed but only sent from the NC to the host computer when data is to be transferred from the
computer but the transfer buffer is still occupied.
3101 Program not in memory Acknowledgement key
S When calling a program via computer link
S None
A program has been requested for read-out but is not located in the NC memory.
This alarm is not displayed in the message line but is only indicated in the operator display.
S Check whether program request is correct
3102 Data input disabled FTR Acknowledgement key
When reading in programs via FTR
FTR is aborted
S You have tried to read in a part program via FTR which has already been edited and executed NC internally.
S “Execution from external”
A program with the same number as the program to be executed from external already exists
Stop execution or delete program in the case of “Execution from external”.
3110 Wrong block structure for axis-specific override Acknowledgement key
(2nd step)
When G160 and G161 commands are not programmed alone in a block
S Interlocking of NC START
S Alter the part program
Applies to SW 2 only
Scan
Effect
Explanation
Remedy
Scan
Effect
Explanation
Scan
Effect
Explanation
Remedy
Scan
Effect
Explanation
Remedy
Scan
Effect
Remedy
Note
1 Alarms
1.5.1 Alarm description
01/99
