Troubleshooting Procedures
3.30 Valve Does Not Go Fully Closed/Open
PS2 Troubleshooting Guide
42 Service Manual, 03/2017, A5E36661550-AA
3.30
Valve Does Not Go Fully Closed/Open
From AUT or MAN mode, press button for 5 seconds.
Observer parameter name in the lower left hand corner.
Continue to press
button until "YCLS" Parameter is reached.
Note: While in configuration mode, the positioner is NOT controlling the valve.
Use
and buttons to change Parameter values:
Set Parameter YCLS to "Up do" (Tight Closing Up and Down
)
To exit configuration mode, press and hold
button for 5 seconds.
Unit should be in Manual Mode.
Press and release
button once to enter AUTO mode.
Verify the valve assembly goes to the fully open and/or closed position with a 0 or 100%
command signal.
If not:
The problem may be the input signal. Use the PS2’s display as a current meter. This
is found in Diagnostic parameter "mA".
Verify unit is in Automatic mode.
Provide a 4 mA input signal.
Press all three buttons down until display changes.
○ Diagnostic menu will be displayed. The diagnostic name can be found in the lower
right corner.
Press the
button to advance through the menu.
While pressing and holding
button, press the button to go backwards in menu.
Go to option "mA".
Observe display and verify if the positioner is actually displaying ≈ 4 mA. If not, then the
input signal is the cause.
To exit diagnostic mode, press and hold
button for 5 seconds.
