Functions
2.12 Auxiliary Functions
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
122
2.12.4.4 Information List
No. Information Type of In-
formation
Comments
- ResMinMax IntSP_Ev Reset Minimum and Maximum counter
397 >V MiMaReset SP >V MIN/MAX Buffer Reset
398 >VphphMiMaRes SP >Vphph MIN/MAX Buffer Reset
399 >V1 MiMa Reset SP >V1 MIN/MAX Buffer Reset
407 >Frq MiMa Reset SP >Frq. MIN/MAX Buffer Reset
859 Va-nMin= MVT Va-n Min
860 Va-nMax= MVT Va-n Max
861 Vb-nMin= MVT Vb-n Min
862 Vb-nMax= MVT Vb-n Max
863 Vc-nMin= MVT Vc-n Min
864 Vc-nMax= MVT Vc-n Max
865 Va-bMin= MVT Va-b Min
867 Va-bMax= MVT Va-b Max
868 Vb-cMin= MVT Vb-c Min
869 Vb-cMax= MVT Vb-c Max
870 Vc-aMin= MVT Vc-a Min
871 Vc-aMax= MVT Vc-a Max
872 Vn Min = MVT V neutral Min
873 Vn Max = MVT V neutral Max
874 V1 Min = MVT V1 (positive sequence) Voltage Minimum
875 V1 Max = MVT V1 (positive sequence) Voltage Maximum
882 fmin= MVT Frequency Minimum
883 fmax= MVT Frequency Maximum
