Functions
2.13 Breaker Control
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
128
Operation using DIGSI
Switchgear can be controlled via the operator control interface with a PC using the DIGSI software. The pro-
cedure to do so is described in the SIPROTEC 4 System Description (Control of Switchgear).
Operation Using the System Interface
Switchgear can be controlled via the serial system interface and a connection to the substation control equip-
ment. For that it is necessary that the required periphery is physically existing in the device as well as in the
substation. Furthermore, certain settings for the serial interface need to be made in the device (see SIPROTEC
4 System Description).
2.13.1.2 Information List
No. Information Type of In-
formation
Comments
- 52Breaker CF_D12 52 Breaker
- 52Breaker DP 52 Breaker
- Disc.Swit. CF_D2 Disconnect Switch
- Disc.Swit. DP Disconnect Switch
- GndSwit. CF_D2 Ground Switch
- GndSwit. DP Ground Switch
31000 Q0 OpCnt= VI Q0 operationcounter=
31001 Q1 OpCnt= VI Q1 operationcounter=
31008 Q8 OpCnt= VI Q8 operationcounter=
