Functions
2.1 General
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
39
2.1.7 EN100-Module
2.1.7.1 Functional Description
The EN100-Module enables integration of the 7RW80 in 100-Mbit communication networks in control and au-
tomation systems with the protocols according to IEC 61850 standard. This standard permits uniform commu-
nication of the devices without gateways and protocol converters. Even when installed in heterogeneous envi-
ronments, SIPROTEC 4 relays therefore provide for open and interoperable operation. Parallel to the process
control integration of the device, this interface can also be used for communication with DIGSI and for inter-
relay communication via GOOSE.
2.1.7.2 Setting Notes
Interface Selection
No special settings are required for operating the Ethernet system interface module (IEC 1850, EN100-
Module). If the ordered version of the device is equipped with such a module, it is automatically allocated to
the interface available for it, namely Port B.
2.1.7.3 Information List
No. Information Type of In-
formation
Comments
009.0100 Failure Modul IntSP Failure EN100 Modul
009.0101 Fail Ch1 IntSP Failure EN100 Link Channel 1 (Ch1)
009.0102 Fail Ch2 IntSP Failure EN100 Link Channel 2 (Ch2)
