Siemens SIPROTEC 7RW80 User Manual

Appendix
A.4 Default Settings
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
220
A.4.3 Binary Output
Table A-4 Output Relay Presettings for All Devices and Ordering Variants
Table A-5 Further Output Relay Presettings for 7RW802*
A.4.4 Function Keys
Table A-6 Applies to All Devices and Ordered Variants
Binary Output Default function Function No. Description
BO1 Relay TRIP 511 Relay GENERAL TRIP command
52Breaker 52 Breaker
BO2 52Breaker 52 Breaker
BO3 52Breaker 52 Breaker
BO4 Fail V balance 167 Failure: Voltage Balance
Fail Ph. Seq. V 176 Failure: Phase Sequence Voltage
VT brk. wire 253 Failure VT circuit: broken wire
BO5 Relay PICKUP 501 Relay PICKUP
Binary Output Default function Function No. Description
BO6 not pre-assigned - -
BO7 not pre-assigned - -
BO8 not pre-assigned - -
Function Keys Default function
F1 Display of the operational indications
F2 Display of the primary operational measured values
F3 Display of the last fault log buffer
F4 not pre-assigned
F5 not pre-assigned
F6 not pre-assigned
F7 not pre-assigned
F8 not pre-assigned
F9 not pre-assigned
