2.1.6 Power System Data 2
Applications
• If the primary reference current of the protected object are set, the device is able to calculate and output the
percentage operational measured values.
2.1.6.1 Description
The general protection data (P.System Data 2) includes parameters common to all functions, i.e. not asso-
ciated with a specific protection or monitoring function. In contrast to the P.System Data 1 as discussed
before, they can be changed with the parameter group.
2.1.6.2 Setting Notes
Rated Values of the System
At address 1101 FullScaleVolt. the reference voltage (phase-to-phase) of the monitored equipment is en-
tered. If these reference values match the primary values of the voltage transformer, they correspond to the
setting at Address 202 (Section 2.1.3.2). They are generally used to show values referenced to full scale.
2.1.6.3 Settings
2.1.6.4 Information List
Addr. Parameter Setting Options Default Setting Comments
1101 FullScaleVolt. 0.10 .. 800.00 kV 20.00 kV Measurem:FullScaleVolt-
age(Equipm.rating)
No. Information Type of In-
formation
Comments
126 ProtON/OFF IntSP Protection ON/OFF (via system port)
356 >Manual Close SP >Manual close signal
501 Relay PICKUP OUT Relay PICKUP
511 Relay TRIP OUT Relay GENERAL TRIP command
561 Man.Clos.Detect OUT Manual close signal detected
4601 >52-a SP >52-a contact (OPEN, if bkr is open)
4602 >52-b SP >52-b contact (OPEN, if bkr is closed)
