Appendix
A.10 Measured Values
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
243
A.10 Measured Values
No. Description Function IEC 60870-5-103 Configurable in Matrix
Type
Information Number
Compatibility
Data Unit
Position
CFC
Control Display
Default Display
- Number of TRIPs= (#of TRIPs=) Statistics - - - - - CFC
- Operating hours greater than (OpHour>) SetPoint(Stat) - - - - - CFC
170.2050 V1 = (V1 =) SYNC function 1 130 1 No 9 1 CFC
170.2051 f1 = (f1 =) SYNC function 1 130 1 No 9 4 CFC
170.2052 V2 = (V2 =) SYNC function 1 130 1 No 9 3 CFC
170.2053 f2 = (f2 =) SYNC function 1 130 1 No 9 7 CFC
170.2054 dV = (dV =) SYNC function 1 130 1 No 9 2 CFC
170.2055 df = (df =) SYNC function 1 130 1 No 9 5 CFC
170.2056 dalpha = (dα =) SYNC function 1 130 1 No 9 6 CFC
621 Va (Va =) Measurement 134 157 No 9 2 CFC
622 Vb (Vb =) Measurement 134 157 No 9 3 CFC
623 Vc (Vc =) Measurement 134 157 No 9 4 CFC
624 Va-b (Va-b=) Measurement 160 145 Yes 3 1 CFC
134 157 No 9 5
625 Vb-c (Vb-c=) Measurement 134 157 No 9 6 CFC
626 Vc-a (Vc-a=) Measurement 134 157 No 9 7 CFC
627 VN (VN =) Measurement 134 118 No 9 1 CFC
629 V1 (positive sequence) (V1 =) Measurement - - - - - CFC
630 V2 (negative sequence) (V2 =) Measurement - - - - - CFC
632 Vsync (synchronism) (Vsync =) Measurement - - - - - CFC
644 Frequency (Freq=) Measurement 134 157 No 9 1 CFC
765 (V/Vn) / (f/fn) (V/f =) Measurement 134 157 No 9 8 CFC CD DD
766 Calculated temperature (V/f) (V/f th=) Measurement - - - - - CFC CD DD
832 Vo (zero sequence) (Vo =) Measurement 134 118 No 9 2 CFC
859 Va-n Min (Va-nMin=) Min/Max meter - - - - - CFC
860 Va-n Max (Va-nMax=) Min/Max meter - - - - - CFC
861 Vb-n Min (Vb-nMin=) Min/Max meter - - - - - CFC
862 Vb-n Max (Vb-nMax=) Min/Max meter - - - - - CFC
863 Vc-n Min (Vc-nMin=) Min/Max meter - - - - - CFC
864 Vc-n Max (Vc-nMax=) Min/Max meter - - - - - CFC
865 Va-b Min (Va-bMin=) Min/Max meter - - - - - CFC
867 Va-b Max (Va-bMax=) Min/Max meter - - - - - CFC
868 Vb-c Min (Vb-cMin=) Min/Max meter - - - - - CFC
869 Vb-c Max (Vb-cMax=) Min/Max meter - - - - - CFC
870 Vc-a Min (Vc-aMin=) Min/Max meter - - - - - CFC
871 Vc-a Max (Vc-aMax=) Min/Max meter - - - - - CFC
872 V neutral Min (Vn Min =) Min/Max meter - - - - - CFC
873 V neutral Max (Vn Max =) Min/Max meter - - - - - CFC
874 V1 (positive sequence) Voltage Minimum (V1
Min =)
Min/Max meter - - - - - CFC
875 V1 (positive sequence) Voltage Maximum
(V1 Max =)
Min/Max meter - - - - - CFC
882 Frequency Minimum (fmin=) Min/Max meter - - - - - CFC
883 Frequency Maximum (fmax=) Min/Max meter - - - - - CFC
888 Pulsed Energy Wp (active) (Wp(puls)) Energy 133 55 No 205 - CFC
