Siemens SIPROTEC 7RW80 User Manual

Functions
2.1 General
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
33
2.1.3.3 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under "Display Additional Settings".
Addr. Parameter Setting Options Default Setting Comments
202 Vnom PRIMARY 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage
203 Vnom SECONDARY 34 .. 225 V 100 V Rated Secondary Voltage (L-L)
206A Vph / Vdelta 1.00 .. 3.00 1.73 Matching ratio Phase-VT To
Open-Delta-VT
209 PHASE SEQ. A B C
A C B
A B C Phase Sequence
210A TMin TRIP CMD 0.01 .. 32.00 sec 0.15 sec Minimum TRIP Command Dura-
tion
211A TMax CLOSE CMD 0.01 .. 32.00 sec 1.00 sec Maximum Close Command Dura-
tion
213 VT Connect. 3ph Van, Vbn, Vcn
Vab, Vbc, VGnd
Vab, Vbc, VSyn
Vab, Vbc
Vph-g, VSyn
Vab, Vbc, Vx
Van, Vbn, Vcn VT Connection, three-phase
214 Rated Frequency 50 Hz
60 Hz
50 Hz Rated Frequency
220 Threshold BI 1 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 1
221 Threshold BI 2 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 2
222 Threshold BI 3 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 3
223 Threshold BI 4 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 4
224 Threshold BI 5 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 5
225 Threshold BI 6 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 6
226 Threshold BI 7 Thresh. BI 176V
Thresh. BI 88V
Thresh. BI 19V
Thresh. BI 176V Threshold for Binary Input 7
232 VXnom PRIMARY 0.10 .. 800.00 kV 20.00 kV Rated Primary Voltage X
233 VXnom SECONDARY 100 .. 225 V 100 V Rated Secondary Voltage X
