Functions
2.2 Voltage Protection 27, 59
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
49
2.2.6 Information List
5131 27 Vp< 10 .. 120 V 45 V 27 Pickup Vp<
5132 27 T Vp< 0.1 .. 5.0 sec 1.0 sec 27 T Vp< Time Delay
5133 Pickup - Time 0.05 .. 1.00 ; 0
0.01 .. 999.00
Pickup - Time
No. Information Type of In-
formation
Comments
234.2100 27, 59 blk IntSP 27, 59 blocked via operation
6503 >BLOCK 27 SP >BLOCK 27 undervoltage protection
6506 >BLOCK 27-1 SP >BLOCK 27-1 Undervoltage protection
6508 >BLOCK 27-2 SP >BLOCK 27-2 Undervoltage protection
6513 >BLOCK 59 SP >BLOCK 59 overvoltage protection
6530 27 OFF OUT 27 Undervoltage protection switched OFF
6531 27 BLOCKED OUT 27 Undervoltage protection is BLOCKED
6532 27 ACTIVE OUT 27 Undervoltage protection is ACTIVE
6533 27-1 picked up OUT 27-1 Undervoltage picked up
6534 27-1 PU CS OUT 27-1 Undervoltage PICKUP w/curr. superv
6537 27-2 picked up OUT 27-2 Undervoltage picked up
6538 27-2 PU CS OUT 27-2 Undervoltage PICKUP w/curr. superv
6539 27-1 TRIP OUT 27-1 Undervoltage TRIP
6540 27-2 TRIP OUT 27-2 Undervoltage TRIP
6565 59 OFF OUT 59 Overvoltage protection switched OFF
6566 59 BLOCKED OUT 59 Overvoltage protection is BLOCKED
6567 59 ACTIVE OUT 59 Overvoltage protection is ACTIVE
6568 59-1 picked up OUT 59-1 Overvoltage V> picked up
6570 59-1 TRIP OUT 59-1 Overvoltage V> TRIP
6571 59-2 picked up OUT 59-2 Overvoltage V>> picked up
6573 59-2 TRIP OUT 59-2 Overvoltage V>> TRIP
17370 >BLOCK Vp< SP >Block Undervoltage protection Vp<
17371 >BLOCK Vp> SP >Block Overvoltage protection Vp>
17372 Vp< picked up OUT Vp< Undervoltage picked up
17373 Vp> picked up OUT Vp> Overvoltage picked up
17374 Vp< TRIP OUT Vp< Undervoltage TRIP
17375 Vp> TRIP OUT Vp> Overvoltage TRIP
Addr. Parameter Setting Options Default Setting Comments
