2.7 SYNCHROCHECK 25
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
99
2.7.7 Settings
Addresses which have an appended "A" can only be changed with DIGSI, under "Display Additional Settings".
Addr. Parameter Setting Options Default Setting Comments
6101 Synchronizing ON
OFF
OFF Synchronizing Function
6102 SyncCB (Setting options depend
on configuration)
None Synchronizable circuit breaker
6103 Vmin 20 .. 125 V 90 V Minimum voltage limit: Vmin
6104 Vmax 20 .. 140 V 110 V Maximum voltage limit: Vmax
6105 V< 1 .. 60 V 5 V Threshold V1, V2 without voltage
6106 V> 20 .. 140 V 80 V Threshold V1, V2 with voltage
6107 SYNC V1<V2> YES
NO
NO ON-Command at V1< and V2>
6108 SYNC V1>V2< YES
NO
NO ON-Command at V1> and V2<
6109 SYNC V1<V2< YES
NO
NO ON-Command at V1< and V2<
6110A Direct CO YES
NO
NO Direct ON-Command
6111A TSUP VOLTAGE 0.00 .. 60.00 sec 0.10 sec Supervision time of V1>;V2> or
V1<;V2<
6112 SYN. DURATION 0.01 .. 1200.00 sec; ∞ 30.00 sec Maximum duration of synchro-
nism-check
6113A 25 Synchron YES
NO
YES Switching at synchronous condi-
tion
6121 Balancing V1/V2 0.50 .. 2.00 1.00 Balancing factor V1/V2
6122A ANGLE ADJUSTM. 0 .. 360 ° 0 ° Angle adjustment (transformer)
6123 CONNECTIONof V2 A-B
B-C
C-A
A-B Connection of V2
6125 VT Vn2, primary 0.10 .. 800.00 kV 20.00 kV VT nominal voltage V2, primary
6150 dV SYNCHK V2>V1 0.5 .. 50.0 V 5.0 V Maximum voltage difference
V2>V1
6151 dV SYNCHK V2<V1 0.5 .. 50.0 V 5.0 V Maximum voltage difference
V2<V1
6152 df SYNCHK f2>f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2>f1
6153 df SYNCHK f2<f1 0.01 .. 2.00 Hz 0.10 Hz Maximum frequency difference
f2<f1
6154 dα SYNCHK α2>α1 2 .. 80 ° 10 ° Maximum angle difference
alpha2>alpha1
6155 dα SYNCHK α2<α1 2 .. 80 ° 10 ° Maximum angle difference
alpha2<alpha1
