4.9 User-defined Functions (CFC)
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
199
Processing Times in TICKS Required by the Individual Elements
Individual Element Number of TICKS
Block, basic requirement 5
Each input more than 3 inputs for generic modules 1
Connection to an input signal 6
Connection to an output signal 7
Additional for each chart 1
Arithmetic ABS_VALUE 5
ADD 26
SUB 26
MUL 26
DIV 54
SQUARE_ROOT 83
Basic logic AND 5
CONNECT 4
DYN_OR 6
NAND 5
NEG 4
NOR 5
OR 5
RISE_DETECT 4
X_OR 5
Information status SI_GET_STATUS 5
CV_GET_STATUS 5
DI_GET_STATUS 5
MV_GET_STATUS 5
SI_SET_STATUS 5
DI_SET_STATUS 5
MV_SET_STATUS 5
ST_AND 5
ST_OR 5
ST_NOT 5
Memory D_FF 5
D_FF_MEMO 6
RS_FF 4
RS_FF_MEMO 4
SR_FF 4
SR_FF_MEMO 4
Control commands BOOL_TO_CO 5
BOOL_TO_IC 5
CMD_INF 4
CMD_CHAIN 34
CMD_CANCEL 3
LOOP 8
