Siemens SIPROTEC 7RW80 User Manual

Appendix
A.8 Information List
SIPROTEC, 7RW80, Manual
C53000-G1140-C233-1, Release date 10.2010
236
235.2119 Function $00 is switched OFF
($00 OFF)
Flx OUT On
Off
* * * LED BO
235.2120 Function $00 is ACTIVE ($00
ACTIVE)
Flx OUT On
Off
* * * LED BO
235.2121 Function $00 picked up ($00
picked up)
Flx OUT On
Off
On
Off
**LED BO
235.2122 Function $00 Pickup Phase A
($00 pickup A)
Flx OUT On
Off
On
Off
**LED BO
235.2123 Function $00 Pickup Phase B
($00 pickup B)
Flx OUT On
Off
On
Off
**LED BO
235.2124 Function $00 Pickup Phase C
($00 pickup C)
Flx OUT On
Off
On
Off
**LED BO
235.2125 Function $00 TRIP Delay Time
Out ($00 Time Out)
Flx OUT On
Off
On
Off
**LED BO
235.2126 Function $00 TRIP ($00 TRIP) Flx OUT On
Off
on * * LED BO
235.2128 Function $00 has invalid settings
($00 inval.set)
Flx OUT On
Off
On
Off
**LED BO
236.2127 BLOCK Flexible Function (BLK.
Flex.Fct.)
Device, General IntSP On
Off
* * * LED BO
253 Failure VT circuit: broken wire
(VT brk. wire)
Measurem.Superv OUT On
Off
**LEDBO
255 Failure VT circuit (Fail VT circuit) Measurem.Superv OUT On
Off
**LEDBO
256 Failure VT circuit: 1 pole broken
wire (VT b.w. 1 pole)
Measurem.Superv OUT On
Off
**LEDBO
257 Failure VT circuit: 2 pole broken
wire (VT b.w. 2 pole)
Measurem.Superv OUT On
Off
**LEDBO
272 Set Point Operating Hours (SP.
Op Hours>)
SetPoint(Stat) OUT On
Off
* * LED BO 135 229 1 Yes
301 Power System fault
(Pow.Sys.Flt.)
Device, General OUT On
Off
On
Off
135 231 2 Yes
302 Fault Event (Fault Event) Device, General OUT * on 135 232 2 Yes
303 sensitive Ground fault (sens Gnd
flt)
Device, General OUT On
Off
320 Warn: Limit of Memory Data ex-
ceeded (Warn Mem. Data)
Device, General OUT On
Off
**LEDBO
321 Warn: Limit of Memory Parameter
exceeded (Warn Mem. Para.)
Device, General OUT On
Off
**LEDBO
322 Warn: Limit of Memory Operation
exceeded (Warn Mem. Oper.)
Device, General OUT On
Off
**LEDBO
323 Warn: Limit of Memory New ex-
ceeded (Warn Mem. New)
Device, General OUT On
Off
**LEDBO
356 >Manual close signal (>Manual
Close)
P.System Data 2 SP * * * LED BI BO 150 6 1 Yes
397 >V MIN/MAX Buffer Reset (>V
MiMaReset)
Min/Max meter SP on * * LED BI BO
398 >Vphph MIN/MAX Buffer Reset
(>VphphMiMaRes)
Min/Max meter SP on * * LED BI BO
399 >V1 MIN/MAX Buffer Reset (>V1
MiMa Reset)
Min/Max meter SP on * * LED BI BO
407 >Frq. MIN/MAX Buffer Reset
(>Frq MiMa Reset)
Min/Max meter SP on * * LED BI BO
409 >BLOCK Op Counter (>BLOCK
Op Count)
Statistics SP On
Off
* LED BI BO
501 Relay PICKUP (Relay PICKUP) P.System Data 2 OUT ON m LED BO 150 151 2 Yes
No. Description Function Type
of In-
for-
matio
n
Log Buffers Configurable in Matrix IEC 60870-5-103
Event Log ON/OFF
Trip (Fault) Log ON/OFF
Ground Fault Log ON/OFF
Marked in Oscill. Record
LED
Binary Input
Function Key
Relay
Chatter Suppression
Type
Information Number
Data Unit
General Interrogation
