during editing is the one, which is assigned in the matrix destination column of the con-
trol display.
Details about the functionality and design of a control display are found in the Display
Editor instuction book, Order Number E50417-H1176-C095.
Figure 4-17 DIGSI
®
4 Display Editor, Default Display Example, Control Display is Similar
Note:
The control display and the default display are generally constructed in the same man-
ner. The same aids are used to design both displays.
