Technical Data
10-37SJ63 Manual
C53000-G1140-C120-1
Bridging Time for Failure/Short Circuit ≥ 50 ms at U ≥ 110 VDC
≥ 20 ms at U ≥ 24 VDC
Alternative Voltage Voltage Supply via Integrated Converter
Bridging Time for Failure/Short Circuit ≥ 10 ms
10.1.3 Binary Inputs and Outputs
Binary Inputs Number
7SJ631*– 11 (configurable)
7SJ632*– 24 (configurable)
7SJ633*– 20 (configurable)
7SJ635*– 37 (configurable)
7SJ636*– 33 (configurable)
Nominal Voltage Range 24 VDC to 250 VDC, bipolar
Switching Thresholds adjustable voltage range with jumpers
– For Nominal Voltages 24/48/60 VDC U
PU
≥ 19 VDC
and 60/110/125 VDC U
DO
≤ 14 VDC
– For Nom. Voltages 110/125 VDC U
PU
≥ 88 VDC
and 220/250 VDC U
DO
≤ 66 VDC
Maximum Permissible Voltage 300 VDC
Impulse Filter on Input 220 nF Coupling Capacitor at 220 V with
recovery time > 60 ms
Power Consumption
7SJ631 7SJ632
7SJ633
7SJ635
7SJ636
Quiescent approx. 4W approx. 5,5 W approx. 7W
Energized approx. 10 W approx. 16 W approx. 20 W
Nominal Power Supply Alternating Voltage
U
H
AC
115 VAC
Permissible Voltage Ranges 92 to 132 VAC
Power Consumption, Quiescent approx. 9 VA
Power Consumption, Energized approx. 13 VA
Current Consumption, Energized
(independent of the control voltage)
Binary Inputs Current
Consumption
BI 1....6
approx. 0,9 mA
BI 8....19
BI 25....36
BI 7
approx. 1,8 mA
BI 20....24
BI 37
