Technical Data
10-4 7SJ63 Manual
C53000-G1140-C120-1
Output Relays
1
) Output Relais for Commands/Annunciations
Number
7SJ631*– 8 (configurable)
7SJ632*– 11 (configurable)
7SJ633*– 11 (configurable)
7SJ635*– 14 (configurable)
7SJ636*– 14 (configurable)
Contacts per Relay 1 NO/form A
Switching Capability MAKE 1000W/VA
BREAK 30 W/VA
40 W resistive
25 W at L/R ≤ 50 ms
Switching Voltage 250 V
Permissible Current per Contact 5 A continuous
and Total Current on common path 30 A for 0.5 s
High-duty relays (motor control)
Number
7SJ631*– –)
7SJ632*– 2 (switchable)
7SJ633*– 2 (switchable)
7SJ635*– 4 (switchable)
7SJ636*– 4 (switchable)
Contacts per Relay 2 NO/form A
Switching Capability MAKE 1000W/VA for 48 V to 250 V
BREAK 1000W/VA for 48 V to 250 V
MAKE 500 W/VA for 24 V
BREAK 500 W/VA for 24 V
Switching Voltage 250 V
Permissible Current per Contact 5 A continuous
and Total Current on common path 30 A for 0.5 s
Maximum Time of closed contact on load 30 s
Permissible relative time of closing onto
load 1 %
1 Live Status Alarm Relay
Contacts 1 changeover contact/form C
Switching Capability MAKE 30 W/VA
BREAK 20 W/VA
30 W resistive
25 W at L/R ≤ 50 ms
Switching Voltage 250 V
Permissible Current 1 A continuous
1
) UL–listed with the following nominal value:
120 V ac Pilot duty, B300
240 V ac Pilot duty, B300
