5-17SJ63 Manual
C53000-G1140-C120-1
Configuration 5
Configuration is the process of customizing the relay for the intended application.
To accomplish this, the following questions must be answered:
• Which functions are needed?
• Which data and measured quantities need to be retrieved via which inputs?
• Which control actions need to be issued via which outputs?
• Which user-definable functions need to be performed in CFC (Continuous Function
Chart)?
• What should the displays look like?
• Which interfaces are to be used?
• Which time source is to be used to synchronize the internal clock?
This chapter describes in details how to configure the 7SJ63.
5.1 Configuration of Functions 5-2
5.2 Configuration of Information, Meaured Values, and Commands 5-6
5.3 Creating User Defined Functions with CFC 5-34
5-41
5.5 Establishing a Control Diagram 5-45
5.6 Serial Ports 5-47
5.7 Date and Time Stamping 5-50
