Technical Data
10-6 7SJ63 Manual
C53000-G1140-C120-1
– Laser Class 1 Under EN 60825–1/ –2 using glass fiber 50/125 µm or
using glass fiber 62.5/125 µm
– Optical Link Signal Attenuation max. 8 dB, with glass fiber 62.5/125 µm
– Channel Distance max. 1.5 km (0.95 miles)
– Character Idle State selectable: factory setting “Light off”
SCADA Interface Profibus–FMS or floating interface for data transfer
IEC 60870–5–103 to a master terminal
RS232
– Connection for flush mounted case rear panel, mounting location “B“
9 pin DSUB port
for panel surface- at the double-deck terminal on the
mounted case case bottom
– Test Voltage 500 V AC
– Transmission Speed min. 4800 Bd, max. 38400 Bd
Factory Setting: 38400 Bd
– Maximum Distance of Transmission 15 meters / 49 feet
RS485
– Connection for Flush Mounted Case rear panel, installation location “B“
9 pin DSUB Port RS 485
for panel surface- at the double-deck terminal on the
mounted case case bottom
Profibus cable
– Test Voltage 500 V AC
– Transmission Speed min. 4800 Bd, max. 38400 Bd
Factory Setting: 38400 Bd
– Maximum Distance of Transmission 1 km / 3280 feet / 0.62 mile
Profibus RS485
– Connection for Flush Mounted Case rear panel, installation location “B“
9 pin DSUB Port RS 485
for panel surface- at the double-deck terminal on the
mounted case case bottom
– Test Voltage 500 V AC
Transmission Speed up to 12 M Baud
– Maximum Distance of Transmission 1 km / 3280 feet / 0.62 mile at≤ 93.75 kBd
500 m /1640 feet /0.31 mile at≤ 187.5 kBd
200 m / 660 feet at ≤ 1.5 MBd
100 m / 330 feet at ≤ 12 MBd
Profibus–FMS
Fibre Optical Link
– Connection integrated ST connector for OWG
direct access,
