Appendix
A-577SJ63 Manual
C53000-G1140-C120-1
7157 46 No influence
Starts 79
Stops 79
No influence 46
7158 BINARY INPUT No influence
Starts 79
Stops 79
No influence Binary Input
7159 3Pol.PICKUP BLK YES
NO
NO 3 Pole Pickup blocks 79
7170 1.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 50-1, 50N-1
7171 1.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 50-2, 50N-2
7172 1.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 67-1, 67N-1
7173 1.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 1. Cycle: 67-2, 67N-2
7174 2.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 50-1, 50N-1
7175 2.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 50-2, 50N-2
7176 2.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 67-1, 67N-1
7177 2.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 2. Cycle: 67-2, 67N-2
7178 3.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 50-1, 50N-1
7179 3.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 50-2, 50N-2
7180 3.Cy: 67(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 67-1, 67N-1
7181 3.Cy: 67(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 3. Cycle: 67-2, 67N-2
7182 4.Cy: 50(N)-1 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 50-1, 50N-1
7183 4.Cy: 50(N)-2 Not Blocked
Blocked Via 79 Auto
Recl.
Not Blocked 4. Cycle: 50-2, 50N-2
Addr. Setting Title Setting Options Default Setting Comments
