SIPROTEC 4 Devices
4-16 7SJ63 Manual
C53000-G1140-C120-1
Password Only authorized personnel shall perform control operations.
Control operations are
protected by passwords.
Interlocking Command outputs are subject to interlocking checks, which can be configured individ-
ually and graphically using the CFC logic too. Standard interlockings, such as ground
switch closed status indication are already contained in the basic settings of the device
when delivered from the factory.
Command Process-
ing Times
Details about the command output time, checkback indication monitoring time, etc.,
are entered within the framework of the settings.
Event Recording All control operations are recorded in the message list with date and time.
