Siemens SIPROTEC PROFINET IO User Manual

2 PROFINET IO in SIPROTEC
2.4 IO Modules
34 SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
IO Module Statistic Values 06
Statistic values 06
Category in the hardware catalog Input data
Data type 6 statistic values (value indication) as Float32 value (floating
point); see Chapter 2.3.4
Data size 24 bytes
Acyclic reading of data Reading of 6 unit IDs as unsigned 16 bit value; see Chapter 2.8.2
Reading from:
• Slot: slot number of the plugged module
• Subslot: 1
• Index: 100
Acyclic writing of data Default setting or resetting of the statistic values using an acyclic
data telegram; see Chapter 2.8.1.
Writing to:
• Slot: slot number of the plugged module
• Subslot: 1
• Index: 100
Parameters None
com_profinet-io_profile_us.book Page 34 Friday, August 17, 2012 1:40 PM
