Siemens SIPROTEC PROFINET IO User Manual

2 PROFINET IO in SIPROTEC
2.4 IO Modules
33SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
IO Module Measured Values 12
IO Module Statistic Values 03
Measured values 12
Category in the hardware catalog Input data
Data type 12 measured values as Float32 value (floating point); see
Chapter 2.3.4
Data size 48 bytes
Acyclic reading of data Reading of 12 unit IDs as unsigned 16 bit value; see
Chapter 2.8.2
Reading from:
• Slot: slot number of the plugged module
•Subslot:1
• Index: 100
Acyclic writing of data None
Parameters None
Statistic values 03
Category in the hardware catalog Input data
Data type 3 statistic values (value indication) as Float32 value (floating
point); see Chapter 2.3.4
Data size 12 bytes
Acyclic reading of data Reading of 3 unit IDs as unsigned 16 bit value; see Chapter 2.8.2
Reading from:
• Slot: slot number of the plugged module
• Subslot: 1
• Index: 100
Acyclic writing of data Default setting or resetting of the statistic values using an acyclic
data telegram; see Chapter 2.8.1.
Writing to:
• Slot: slot number of the plugged module
• Subslot: 1
• Index: 100
Parameters None
com_profinet-io_profile_us.book Page 33 Friday, August 17, 2012 1:40 PM
