2 PROFINET IO in SIPROTEC
2.4 IO Modules
32 SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
IO Module Double-Point Indications 08
IO Module Measured Values 06
Double-point indications 08
Category in the hardware catalog Input data
Data type 8 double-point indications; see Chapter 2.3.3
Data size 2 bytes
Acyclic reading/writing of data None
Parameters Each single-point indication can be assigned to the process alarm
(see Chapter 2.7).
Default setting: all not assigned
Measured values 06
Category in the hardware catalog Input data
Data type 6 measured values as Float32 value (floating point); see
Chapter 2.3.4
Data size 24 bytes
Acyclic reading of data Reading of 6 unit IDs as unsigned 16 bit value; see Chapter 2.8.2
Reading from:
• Slot: slot number of the plugged module
• Subslot: 1
• Index: 100
Acyclic writing of data None
Parameters None
