4 PROFINET IO Diagnosis
4.1 Diagnosis HTML Page of EN100
88 SIPROTEC 4, Communication Module PROFINET IO, Communication Profile
C53000-L1840-C360-1, Edition 08.2012
The PROFINET IO diagnosis page contains the following information blocks:
• IO device
• IO modules
• Telegram receive/transmit statistics
• LLDP neighborhood information
•Event list
IO Device
IO Modules
The following table shows the IO modules parameterized in the IO controller for the SIPROTEC device and the
status of these IO modules in the SIPROTEC IO device.
Diagnosis Description
Status Communication status with IO controller (online or offline)
Station name Station name of the SIPROTEC device
Function
Location
Installation date
Description
Identification and Maintenance data I&M1 through I&M3 stored in the device and
written via acyclic PROFINET IO telegrams (see Chapter 4.3)
MAC addresses X1: Interface MAC address
P1, P2: Port MAC addresses
FO power budget Fiber optical power budget of the receive signal on the ports P1 and P2 in dB
NOTE
The IO modules table only contains entries if the SIPROTEC IO device communicates with the IO controller.
IO modules in the SIPROTEC device are plugged dynamically as specified by the parameterization in the IO
controller when the communication is initialized.
If no PROFINET IO communication exists, no IO modules are plugged.
Diagnosis Description
Slot Slot number (18 IO modules max. plus DAP can be plugged)
Module name Name of the plugged IO module
Module ID Identification number of the module type as per GSD file
Subslot Subslot number
IO direction Data direction (input data or output data)
