Requirements
Supported Firmware Versions of SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 10/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
Use of the STARTER configuration tool
The STARTER configuration tool associated to SINAMICS S120 is
integrated in the S7T Config configuration software for the technology CPU.
The installation of the “stand alone” version of STARTER together with S7T
Config on a shared partition of the development computer is not possible.
2.2 Firmware versions supported by S7T Config
The STARTER configuration and commissioning tool integrated in
S7T Config supports the respective firmware versions of the SINAMICS
S120 drive system up to a specific version.
If SINAMICS S120 is to be configured and commissioned via S7T Config,
the drive system has to be equipped with the respective firmware version
suitable for S7T Config.
Note
A manual for updating the respective firmware version of SINAMICS
S120 is included in the respective firmware software or can be
downloaded from the internet together with the firmware software.
Supported firmware versions
The respective version of the S7 Technology program package supports
the configuration and the commissioning of the SINAMICS S120 drive
system up to the following firmware version:
Table 2-1 Supported firmware versions
S7 Technology version Firmware version SINAMICS S120
S7 Technology V2.0 ≤ FW 2.1
S7 Technology V2.0 SP1 ≤ FW 2.2
This documentation describes the commissioning of SINAMICS S120 with
firmware version 2.2 via S7 Technology V2.0 SP1. If other firmware
combinations are used, the described processes may deviate from the
activities to be performed.
