Requirements
Data Backup of SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 29/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
Figure 4-4 Permanent storing of the loaded data – Copy RAM to ROM
4.3.2 Data backup in a STEP 7 project
All parameters and BICO interconnections can also be backed up and
archived in a STEP 7 project. This requires that the data are loaded from
SINAMICS S120 to the STEP 7 project.
Backing up the data
To back up the data, proceed as follows:
Table 4-3 Backup of the drive data
No. Instruction Note
1.
In the Project menu, establish the
online connection to SINAMICS
S120 by selecting the menu item
Connect to target system.
To Next Page
