Commissioning SINAMICS S120
Preparing SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 33/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
5.3 Restoring factory settings
To create a safe initial situation for commissioning SINAMICS S120, the
drive system has to be reset to factory settings.
!
Attention
Before restoring the factory settings, it is useful to back up the data
at SINAMICS S120 to be able to possibly restore the initial state.
To restore the factory settings, open your project with the configured
SINAMICS S120 in the SIMATIC Manager and proceed as follows:
Table 5-1 Restoring the factory settings
No. Instruction Note
1.
In the SIMATIC Manager, select
SINAMICS_S120 and double-click
this component in the right
window.
This starts S7T Config for
SINAMICS S120.
2.
In the Project menu, establish the
online connection to SINAMICS
S120 by selecting the menu item
Connect to target system.
3.
Start restoring the factory settings
via the Restore factory settings
context menu of SINAMICS_S120.
