Commissioning SINAMICS S120
Commissioning SINAMICS S120
SINAMICS S120 at Technology CPU Entry ID: 21767896
V1.0 Edition 10/28/05 36/58
Copyright © Siemens AG 2005 All rights reserved
SINAMICS S120 und Technologie-CPU V2.0-SP1__05-10-28_13-20_e.doc
No. Instruction Note
4.
Click the Start automatic
configuration button to start the
automatic configuration.
5.
Select the Servo type for the Drive
Object Type via the radio buttons.
All settings in the table are then set
to this type.
6.
Acknowledge the message on the
manual configuration of the
component SERVO_03 by clicking
the OK button.
7.
After successful upload, Running
operation reports the status
Automatic configuration is
completed.
Close the message window by
clicking Close.
8.
The automatic configuration of the
DRIVE-CLiQ components is now
completed.
9.
Switch to offline mode by selecting
the menu item Disconnect from
target system.
