OPERATION 6
47
SITRANS FX300
www.siemens.com/flow06/2009 - SFIDK.PS.050.F2.02 A5E02100423
6.5 Menu structure
6.5.1 Overview of firmware versions
There are three firmware versions, each of which is tailored to a different use of the
measuring device:
• Basic:
Basic:Basic:
Basic: liquids and gases without compensation, saturated steam with density compensation
using the temperature
• Steam:
Steam:Steam:
Steam: saturated and superheated steam with density compensation using pressure and
temperature, gross heat meter
• Gas:
Gas:Gas:
Gas: gas, gas mixture and wet gas with density compensation using pressure and
temperature, FAD (free air delivery measurement)
The menu structures differ from one another depending on the firmware version.
The following table contains an overview of all menu items in the first menu level. For a
complete description of the menu, note the firmware version of your measuring device and
follow the relevant instructions in the table.
Menu items Firmware version
Basic
Firmware version
Steam
Firmware version
Gas
1. Quick setup refer to
Menu item Quick Setup
on page 49
2. Tests refer to
Menu item Tests
on page 50
3. Setup refer to
Menu item
Setup (firmware version
- basic)
on page 51
refer to
Menu item
Setup (firmware version
- steam)
on page 54
refer to
Menu item
Setup (firmware version
- gas)
on page 58
5. Service The service menu is only accessible to service personnel and is not described.
Table 6-9: Overview of menu structure
INFORMATION!
The measuring device has been preset at the factory in accordance with the customer order.
Therefore, subsequent configuration via the menu is only necessary if the intended use of the
measuring device changes.
