6.5.4 Menu item Quick Setup
Level Designation Selection / entry field Explanation
1.1.1 Language
→
Select menu language
German ↑... German language
French ↑… French language
English ↑...^ English language
1.1.2 Location
→
0000000000
Location↑…↑...↑...^
Enter the name of the location (max.
10 characters)
1.1.3 Maes.Inst
→
Select type of flow measurement
Volume ↑… Volume measurement
Norm. Vol. ↑… 1 Standard volume flow measurement
Mass ↑...^ Mass flow measurement
1.1.4 Max. Flow
→
Set maximum flow rate
2
m
3
/h
Unit ↑...^
Select unit for volume flow
measurement
888888888
Upp.Limit
00600.0000 or other value
m
3
/h ↑…↑...↑...^
Enter value for the maximum volume
flow
Display Unit /
Display %Max Flow ↑...^
Display flow rate in units /
in % of maximum flow rate
3
m
3
/h norm
Unit ↑...^
Select unit for standard volume flow
measurement
00600.0000 or other value
m
3
/h norm ↑…↑...↑...^
Enter value for the maximum
standard volume flow rate
Display Unit /
Display %Max Flow ↑...^
Display flow rate in units /
in % of maximum flow rate
4
kg/h
Unit
Select unit for mass flow
measurement
00600.0000 or other value
kg/h ↑…↑...↑...^
Enter value for the maximum mass
flow rate
Display Unit /
Display %Max Flow ↑...^
Display flow rate in units /
in % of maximum flow rate
1.1.5 Min. Flow
→
001111111
00300.0000
m
3
/h ^
The minimum flow rate value is
factory-set.
1.1.6 Timeconst.
→
00002.0000
s ↑…↑...↑...^
Enter the time constant for the
measured value output in seconds
(0–20s)
0: disabled
1 only with gas
2 available if Maes.Inst = Volume (see menu item 1.1.3)
3 available if Maes.Inst = Norm. Vol. (see menu item 1.1.3)
4 available if Maes.Inst = Mass (see menu item 1.1.3)
