Siemens SITRANS FX300 User Manual

6 OPERATION
50
SITRANS FX300
www.siemens.com/flow 06/2009 - SFIDK.PS.050.F2.02 A5E02100423
6.5.5 Menu item Tests
Every current value has to be confirmed with ^. Only after this is the current output
set to the respective value. The following is then displayed:
• "Contin. Yes":
"Contin. Yes":"Contin. Yes":
"Contin. Yes": continue with the test of current output function
• "Contin. No":
"Contin. No":"Contin. No":
"Contin. No": back to menu
The test current is maintained until the menu has been exited.
Level Designation Selection / entry Explanation
2.1.1 Test I
→
4 mA ^ Test current output
8 mA ^
12 mA ^
16 mA ^
20 mA ^
2.1.2 Test P
→
0.5003 Hz ^ Test pulse output
Table 6-10: Menu item Test
MA_Siemens_Sitrans_FX300_R02_en_PRT.book Page 50 Monday, June 22, 2009 8:17 AM
