10.3 Degrees of protection according
to IEC 60529
IEC 60529 establishes a classification system for degrees of
protection ensured by an enclosure which relates to electri-
cal equipment of a voltage rating up to 72.5 kV. The IP code
(IP = international protection) described in this standard
characterises the degrees of protection against access to
hazardous parts, ingress of solid foreign bodies and the
ingress of water which are ensured by an enclosure. It is
briefly summarized in Tab. 10/3.
Tab. 10/3: Structure of the IP code and the meaning of code numerals and code letters
Code constituent Code letter or code number
Meaning for the protection of
equipment
Meaning for the safety of
persons
International protection
IP
- -
1
st
code number: Against the ingress of solid bodies Against access to dangerous parts
0
-
(not protected)
-
(not protected)
1
≥ 50.0 mm in diameter back of the hand
2
≥ 12.5 mm in diameter finger
3
≥ 2.5 mm in diameter tool
4
≥ 1.0 mm in diameter wire
5
dust-protected wire
6
dust-proof wire
2
nd
code number:
Against the ingress of water with a
damaging effect
-
0
-
(not protected)
1
vertical drops
2
drops to an angle of 15°
(enclosure tilt 15°)
3
spray water
4
splash water
5
jet water
6
powerful jet water
7
temporary immersion
8
continuous immersion
Additional letter (optional) -
Against access to dangerous parts
with a
A
back of the hand
B
finger
C
tool
D
wire
Additional letter (optional)
Supplementary information
especially for
-
H
high-voltage devices
M
movement during water test
S
standstill during water test
W
weather conditions
