SIVACON S8 Planning Principles – Further planning notes
8.2 Weights and power loss
Weight data in Tab. 8/1 is for orientation only. The same
applies to the power losses specified in Tab. 8/2. This data
represents approximate values for a cubicle with the main
circuit of functional units for determination of the power
loss to be dissipated from the switchboard room. Power
Tab. 8/1: Weights of SIVACON S8 cubicles (orientation values)
Cubicle dimensions
Nominal current
Average weights of the cubicles including busbar
(without cable)
Height Width Depth
Circuit-breaker cubicles
2,200 mm
400 mm
500 mm 630 - 1,600 A
340 kg
600 mm 390 kg
600 mm
600 mm 2,000 - 3,200 A
510 kg
800 mm 545 kg
800 mm
600 mm
4,000 A 770 kg
800 mm
1,000 mm 800 mm 4,000 - 6,300 A 915 kg
Universal / fixed-mounted design
2,200 mm 1,000 mm
500 mm 400 kg
600 mm 470 kg
800 mm 590 kg
In-line design, fixed-mounted
2,200 mm
600 mm 600 mm 360 kg
800 mm 800 mm 470 kg
In-line design, plug-in
2,200 mm 1,000 mm
500 mm 415 kg
600 mm 440 kg
800 mm 480 kg
Reactive power compensation
2,200 mm 800 mm
500 mm 860 kg
600 mm 930 kg
800 mm 1,050 kg
losses of possibly installed additional auxiliary devices must
also be taken into consideration. Further information is
available from your Siemens contact.
Circuit-breaker design with
3WL (withdrawable unit)
Power loss (approx. value) P
V
Circuit-breaker design with
3VL (withdrawable unit)
Power loss (approx. value) P
V
100% rated
current
80 % rated
current
100% rated
current
80 % rated
current
3WL1106 (630 A, Bg. I)
215 W 140 W
3VL630 (630 A)
330 W 210 W
3WL1108 (800 A, Bg. I)
345 W 215 W
3VL800 (800 A)
440 W 290 W
3WL1110 (1,000 A Bg. I)
540 W 345 W
3VL1250 (1,250 A)
700 W 450 W
3WL1112 (1,250 A, Bg. I)
730 W 460 W
3VL1600 (1,600 A)
1,140 W 730 W
3WL1116 (1,600 A, Bg. I)
1,000 W 640 W
Fixed-mounted design
P
V
= approx. 600 W
3WL1220 (2,000 A, Bg. II)
1,140 W 740 W
In-line design, fixed-mounted
P
V
= approx. 600 W
3WL1225 (2,500 A, Bg. II)
1,890 W 1,210 W
In-line design, plug-in
P
V
= approx. 1,500 W
3WL1232 (3,200 A, Bg. II)
3,680 W 2,500 W
Withdrawable-unit design
P
V
= approx. 600 W
3WL1340 (4,000 A, Bg. III)
4,260 W 2,720 W
Reactive power compensation
Power loss (approx. value) P
V
3WL1350 (5,000 A, Bg. III)
5,670 W 3,630 W
Non-choked
1.4 W/kvar
3WL1363 (6,300 A, Bg. III)
8,150 W 5,220 W
Choked
6.0 W/kvar
Tab. 8/2: Power losses of SIVACON S8 cubicles (orientation values)
