SIVACON S8 Planning Principles – Technical annex
2
3
4
5
6
7
8
9
10
11
1
Standard power P
Motor current I (guide value)
at 400 V at 500 V at 690 V
0.06 kW
0.20 A 0.16 A 0.12 A
0.09 kW
0.30 A 0.24 A 0.17 A
0.12 kW
0.44 A 0.32 A 0.23 A
0.18 kW
0.60 A 0.48 A 0.35 A
0.25 kW
0.85 A 0.68 A 0.49 A
0.37 kW
1.1 A 0.88 A 0.64 A
0.55 kW
1.5 A 1.2 A 0.87 A
0.75 kW
1.9 A 1.5 A 1.1 A
1.1 kW
2.7 A 2.2 A 1.6 A
1.5 kW
3.6 A 2.9 A 2.1 A
2.2 kW
4.9 A 3.9 A 2.8 A
3 kW
6.5 A 5.2 A 3.8 A
4 kW
8.5 A 6.8 A 4.9 A
5.5 kW
11.5 A 9.2 A 6.7 A
7.5 kW
15.5 A 12.4 A 8.9 A
11 kW
22 A 17.6 A 12.8 A
15 kW
29 A 23 A 17 A
18.5 kW
35 A 28 A 21 A
22 kW
41 A 33 A 24 A
30 kW
55 A 44 A 32 A
37 kW
66 A 53 A 39 A
45 kW
80 A 64 A 47 A
55 kW
97 A 78 A 57 A
75 kW
132 A 106 A 77 A
90 kW
160 A 128 A 93 A
110 kW
195 A 156 A 113 A
132 kW
230 A 184 A 134 A
160 kW
280 A 224 A 162 A
200 kW
350 A 280 A 203 A
250 kW
430 A 344 A 250 A
Tab. 10/5: Guide values for the operating currents of three-phase
asynchronous motors (AC-2/AC-3) in accordance with IEC 60947-4-1
10.5 Operating currents of three-
phase asynchronous motors
To enable the conversion of motor power values, Tab. 10/5
specifies guide values for the motor current present with
different voltages.
