8
SIVACON S8 Planning Principles – SIVACON S8 – System overview
• Safety - integrated
• Economic efficiency - right from the start
• Flexibility – through modularity
The interaction of the components described below results
in an optimal low-voltage switchboard with advantages as
regards:
2 SIVACON S8 – System overview
Standards and approvals
Standards and regulations Power switchgear and controlgear assembly
(design verification)
IEC 61439-2
DIN EN 61439-2-2
VDE 0660-600-2
Test of internal fault behaviour (internal arc) IEC/TR 61641
DIN EN 60439-1 Supplement 2
VDE 0660-500 Supplement 2
Induced vibrations IEC 60068-3-3
IEC 60068-2-6
IEC 60068-2-57
IEC 60980
KTA 2201.4
Uniform Building Code (UBC), Edition 1997 Vol. 2,
Ch. 19, Div. IV
Protection against electric shock EN 50274 (VDE 0660-514)
Approvals Europe
Russia, Belarus, Kasakhstan
China
CE marking and EC Declaration of Conformity
EAC
CCC
Det Norske Veritas
Lloyds Register of Shipping
DNV GL Type Approval Certificate
LR Type Approval Certificate
Shell conformity "DEP Shell"
Technical data
Installation conditions Indoor installation, ambient temperature in the
24-h mean
+ 35 °C
(-5 °C to + 40 °C)
Rated operating voltage (U
e)
Main circuit
Up to 690 V (rated frequency f
n
50 Hz)
Dimensioning of creepage
distances and clearances
Rated impulse withstand voltage U
imp
8 kV
Rated
insulation voltage (U
i
)
1,000 V
Degree of pollution 3
Main busbars, horizontal Rated current Up to 7,010 A
Rated peak withstand current (I
pk
)
Up to 330 kA
Rated short-time withstand current (I
cw
)
Up to 150 kA, 1s
Rated device currents Circuit-breakers Up to 6,300 A
Cable feeders Up to 630 A
Motor feeders Up to 630 A
Internal separation IEC 61439-2 Form 1 to form 4
BS EN 61439-2 Up to form 4 type 7
IP degree of protection in accordance with IEC 60529 Ventilated up to IP43
Non-ventilated IP54
Mechanical strength IEC 62262 Up to IK10
Dimensions Height (without base) 2,000, 2,200 mm
Height of base (optional) 100, 200 mm
Cubicle width 200, 350, 400, 600, 800, 850, 1,000, 1,200, 1,400 mm
Depth (single-front) 500, 600, 800, 1,000, 1,200 mm
Tab. 2/1: Technical data, standards and approvals for the SIVACON S8 switchboard
