SIVACON S8 Planning Principles – Universal mounting design
Small withdrawable unit
1)
Motor
power P
(AC-2/AC3)
Minimum withdrawable unit size at 35 °C ambient
temperature
Height 150 mm Height 200 mm
Direct
contactor
Reversing
circuit
Direct
contactor
Reversing
circuit
0.25 kW
½ ½ ¼, ½ ¼, ½
0.37 kW
½ ½ ¼, ½ ¼, ½
0.55 kW
½ ½ ¼, ½ ¼, ½
0.75 kW
½ ½ ¼, ½ ¼, ½
1.1 kW
½ ½ ¼, ½ ¼, ½
1.5 kW
½ ½ ¼, ½ ¼, ½
2.2 kW
½ ½ ¼, ½ ¼, ½
3 kW
½ ½ ¼, ½ ¼, ½
4 kW
½ ½ ¼, ½ ¼, ½
5.5 kW
½ ½ ¼, ½ ¼, ½
7.5 kW
½ ½ ¼, ½ ¼, ½
11 kW
½ ½ ½ ½
15 kW
- - ½ ½
18.5 kW
- - ½ -
22 kW
- - ½ -
30 kW
- - ½ -
Tab. 4/22: Minimum withdrawable unit sizes for:
fuseless motor feeders, 400 V, CLASS 10,
with SIMOCODE, type 2 at 50 kA
Normal withdrawable unit
Motor
power P
(AC-2/AC3)
Minimum withdrawable unit height at 35 °C
ambient temperature
Direct
contactor
Reversing
circuit
Star-delta
0.25 kW
100 mm 100 mm 150 mm
0.37 kW
100 mm 100 mm 150 mm
0.55 kW
100 mm 100 mm 150 mm
0.75 kW
100 mm 100 mm 150 mm
1.1 kW
100 mm 100 mm 150 mm
1.5 kW
100 mm 100 mm 150 mm
2.2 kW
100 mm 100 mm 150 mm
3 kW
100 mm 100 mm 150 mm
4 kW
100 mm 100 mm 150 mm
5.5 kW
100 mm 100 mm 150 mm
7.5 kW
100 mm 100 mm 150 mm
11 kW
150 mm 150 mm 150 mm
15 kW
150 mm 150 mm 200 mm
18.5 kW
200 mm 250 mm 250 mm
22 kW
200 mm 250 mm 250 mm
30 kW
200 mm 250 mm 250 mm
37 kW
200 mm 250 mm 250 mm
45 kW
200 mm 250 mm 250 mm
55 kW
300 mm 400 mm 400 mm
75 kW
300 mm 400 mm 400 mm
90 kW
300 mm 400 mm 400 mm
110 kW
400 mm 500 mm 500 mm
132 kW
500 mm 500 mm 700 mm
160 kW
500 mm 500 mm 700 mm
200 kW
600 mm 700 mm 700 mm
250 kW
600 mm 700 mm 700 mm
1)
Type: ¼ = small withdrawable unit size ¼
½ = small withdrawable unit size ½
Tab. 4/21: Minimum withdrawable unit sizes for:
fuseless motor feeders, 400 V, CLASS 10,
with overload relay, type 2 at 50 kA
Small withdrawable unit
1)
Motor
power P
(AC-2/AC3)
Minimum withdrawable unit size at 35 °C ambient
temperature
Height 150 mm Height 200 mm
Direct
contactor
Reversing
circuit
Direct
contactor
Reversing
circuit
0.25 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
0.37 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
0.55 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
0.75 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
1.1 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
1.5 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
2.2 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
3 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
4 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
5.5 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
7.5 kW
¼, ½ ¼, ½ ¼, ½ ¼, ½
11 kW
½ ½ ½ ½
15 kW
½ ½ ½ ½
18.5 kW
½ - ½ ½
22 kW
½ - ½ ½
30 kW
- - ½ -
Normal withdrawable unit
Motor
power P
(AC-2/AC3)
Minimum withdrawable unit height at 35 °C
ambient temperature
Direct contactor
Reversing
circuit
Star-delta
0.25 kW
100 mm 100 mm 150 mm
0.37 kW
100 mm 100 mm 150 mm
0.55 kW
100 mm 100 mm 150 mm
0.75 kW
100 mm 100 mm 150 mm
1.1 kW
100 mm 100 mm 150 mm
1.5 kW
100 mm 100 mm 150 mm
2.2 kW
100 mm 100 mm 150 mm
3 kW
100 mm 100 mm 150 mm
4 kW
100 mm 100 mm 150 mm
5.5 kW
100 mm 100 mm 150 mm
7.5 kW
100 mm 100 mm 150 mm
11 kW
100 mm 100 mm 150 mm
15 kW
100 mm 100 mm 150 mm
18.5 kW
150 mm 150 mm 200 mm
22 kW
150 mm 150 mm 200 mm
30 kW
150 mm 250 mm 250 mm
37 kW
150 mm 250 mm 250 mm
45 kW
150 mm 250 mm 250 mm
55 kW
300 mm 400 mm 400 mm
75 kW
300 mm 400 mm 400 mm
90 kW
300 mm 400 mm 400 mm
110 kW
400 mm 500 mm 500 mm
132 kW
500 mm 500 mm 700 mm
160 kW
500 mm 500 mm 700 mm
200 kW
700 mm 700 mm 700 mm
250 kW
700 mm 700 mm 700 mm
1)
Type: ¼ = small withdrawable unit size ¼
½ = small withdrawable unit size ½
