PROFIBUS Interface Center SPC3
Page 60 V1.3 SPC3 Hardware Description
2003/04 Copyright (C) Siemens AG 2003. All rights reserved.
10.2 General Definition of Terms
ASPC2 Advanced Siemens PROFIBUS Controller, 2
nd
generation
SPC2 Siemens PROFIBUS Controller, 2
nd
generation
SPC3 Siemens PROFIBUS Controller, 3
rd
generation
SPM2 Siemens PROFIBUS Multiplexer, 2
nd
generation
LSPM2 Lean Siemens PROFIBUS Multiplexer, 2
nd
generation
DP Distributed I/Os
FMS Fieldbus Message Specification
MS MicroSequenzer
SM State Machine
10.3 Ordering of ASICs
For Ordering SPC3 ASICs please refer to your contact person in the Siemens local branch office and use
one of the ordering numbers depending on the amount you want to order.
10.3.1 SPC3 (AMI)
ASIC SPC 3 6ES7 195-0BD02-0XA0 Small amount 5
(STEP C) 6ES7 195-0BD12-0XA0 Single-Tray 96
6ES7 195-0BD22-0XA0 Tray-Box 576
6ES7 195-0BD32-0XA0 8 Tray-Box 4608
6ES7 195-0BD42-0XA0 17 Tray-Box 9792
10.3.2 SPC3 (ST)
ASIC SPC 3 6ES7 195-0BD01-0XA0 Kleinverpack. 5
(STEP C) 6ES7 195-0BD11-0XA0 Einzel-Tray 96
6ES7 195-0BD21-0XA0 Tray-Box 576
6ES7 195-0BD31-0XA0 8 Tray-Box 4608
6ES7 195-0BD41-0XA0 17 Tray-Box 9792
