Siemens XPS - Model Specific Certifications and Warnings; XCT-8 Ultrasonic Transducer Details; XCT-12 Ultrasonic Transducer Details; Example Configuration and Serial Number Note

A5E32282889 XPS/XCT Series Transducers – OPERATION MANUAL Page EN-5
mmmmm
English
XCT-8
XCT-12
Note:
• Product configuration number shown for example only.
• Serial number shown for example only.
XCT-8 ULTRASONIC TRANSDUCER
Serial No: GYZ / A1034567
Ambient Temp.: – 40 °C to 145 °C
V in: 1.77 V r.m.s.; 250 Vp
Iin:44.2mAr.m.s.
Enclosure: IP66, IP68
0518
SIRA 99ATEX5153X
II2GD
EExmIIT3
Siemens Milltronics Process Instruments, Peterborough
ATENÇÃO - RISCO POTENCIAL
DE CARGA ELETROSTÁTICA
- VEJA INSTRUÇÕES
KCC-REM-S49
Echomax
Static Hazard,
Do Not Rub With Dry Cloth.
WARNING:
Class I, Zone 1,
ExsIT4,Amb.Temp.:–40°C to 95°C
IC 3 145
DIPIP65/IP67
AEx X
Ex s I T , Amb. Temp.: –40°C to °C
NZ 08.3066
Class I, Div 2, Group A, B, C, D
Class II, Div 2, Group F, G
Per Dwg.: 0-9650017Z-DI-A
Max. Torque: 15 FT–LBS
Ex mb IIC T3 Gb
Ex tb IIIC T135 °C Db
DNV 12.0077 X
OCP 0017
Ex mb IIC T3 Gb
Ex tb IIIC T135 °C Db
DNV 12.0077 X
XCT-12 ULTRASONIC TRANSDUCER
Serial No: GYZ / A1034567
Ambient Temp.: – 40 °C to 145 °C
V in: 1.77 V r.m.s.; 250 Vp
I in : 44.2 mA r.m.s.
SIRA 99ATEX5153X
II2GD
EExmIIT3
Siemens Milltronics Process Instruments, Peterborough
Enclosure: IP66, IP68
OCP 0017
Static Hazard,
Do Not Rub With Dry Cloth.
WARNING:
ClassI,Zone1
ExsIT4,Amb.Temp.: 9
,
DIP IP65 / 67
AEx X
–40°Cto 5°C
ExsIICT3 Amb.Temp.:–40°Cto145°C
IP
NZ 08.3066
Class I, Div 2, Group A, B, C, D
Class II, Div 2, Group F, G
Per Dwg.: 0-9650017Z-DI-A
Max. Torque: 15 FT–LBS
0518
ATENÇÃO - RISCO POTENCIAL DE CARGA
ELETROSTÁTICA - VEJA INSTRUÇÕES
KCC-REM-S49
Echomax
